New design water cutting machine
EAAK new design water jet cutting machine EK1020N is with compelte new color and new structure design, can save more space and works steady.
Specification of EAAK CNC water jet cutting machine:(as follows)
Parameters of CNC waterjet cutter working on different materials such as glass,metal,stone(as follows)
Specification of EAAK CNC water jet cutting machine:(as follows)
| Model | EK3020N |
| X Y axis Working size | 3000mm*2000mm |
| Z working height | 150mm |
| Cutting Pressure | 420Mpa 37kw UHP pump |
| Control accuracy | 0.01mm |
| Cutting accuracy | 0.1-0.2mm |
| Repositioning Accuracy | 0.05mm |
| Max cutting thickness | 300mm(depends on materials) |
| Max. moving speed | 6000mm/min |
| Power supply | 380V 50Hz |
| Environmental temperature | -10-50°C |
| Max flow rate | 3.7L/min |
| Max oil discharge | 206L/min |
| Max delivery capacity of oil pump | 106L/min |
| Control system | Ncstudio (Shanghai) software IPC controller |
| CAD/CAM software | AutoCAD,ArtCAM |
| Drive motor | Japan Yaskawa servo drive motor |
| Materials | Thickness | Cutting speed (mm/min) | ||
| 380Mpa | 420Mpa | 600Mpa | ||
| Normal glass cutting | 6 mm | 1400-1500 | 2100-2250 | 2520-2700 |
| 8 mm | 690-800 | 1035-1200 | 1242-1440 | |
| 19mm | 400-500 | 600-750 | 950-1150 | |
| Granite panel cutting | 20mm | 260-300 | 390-450 | 468-540 |
| 30mm | 170-200 | 255-300 | 306-360 | |
| Porcelain tile cutting | 10mm | 900-1000 | 1350-1500 | 1620-1800 |
| Marble panel cutting | 10mm | 600-900 | 900-1350 | 1080-1620 |
| 20mm | 350-400 | 526-600 | 630-720 | |
| 30mm | 260-300 | 390-450 | 468-540 | |
| Laminating glass cutting | 21mm | 490-600 | 735-900 | 882-1080 |
| Sponge and foam cutting | 20mm | 6000-7000 | 9000-10500 | 10800-12600 |
| 50mm | 2600-3000 | 3900-4500 | 4680-5400 | |
| 80mm | 1600-2000 | 2400-3000 | 2880-3600 | |
| Steel plate cutting | 10mm | 170-220 | 255-330 | 306-396 |
| 20mm | 75-100 | 113-150 | 135-180 | |
| 30mm | 15-30 | 22-45 | 27-54 | |
| Stainless steel plate cutting | 1 mm | 1000-1200 | 1500-1800 | 1800-2160 |
| 3 mm | 500-600 | 750-900 | 900-1080 | |
| 6 mm | 240-300 | 360-450 | 432-540 | |
| 10mm | 150-180 | 225-270 | 270-324 | |
| 16mm | 85-100 | 128-150 | 153-180 | |
| 20mm | 70-80 | 105-120 | 126-144 | |
| 30mm | 30-40 | 45-60 | 54-72 | |
| Copper plate cutting | 3 mm | 1350-1500 | 2025-2250 | 2430-2700 |
| 5 mm | 700-850 | 1050-1275 | 1260-1530 | |
| 20mm | 160-200 | 240-300 | 288-360 | |
| 30mm | 100-120 | 150-180 | 180-216 | |
| Titanium alloy cutting | 13mm | 100-115 | 150-173 | 180-207 |
